De viktigste funksjonene og produktfordelene er:
Ekstra valgfri programvare:
KB-Copy Ver2
– enkel Scan2File og Scan2Copy programvare inkludert zoomfunksjon.
Aupier-GigaStitch
– programvare for profesjonell bilderedigering og søm.
Camera Sensor | RGB line sensor (3-channel, CMOS technology) |
Resolution | MeanMTF10 at 600 ppi: 9 LP/mm (with max. zoom-in up to 12 LP/mm) |
Recording system | wear-free mechanical shutter, variable exposure time, electronically adjustable shutter; automatic white and black balance, variable depth of focus |
Max. original size | >DIN A1, depending on book cradle |
Max. book thickness | with book cradle OT 180 H 35 XL – 35 cm with book cradle OT 180 H 50 XL – 50 cm |
Scan unit | CMOS RGB sensor |
Scan mode | 96 bit color |
Scanning Speed | (from start to end of scanning process) in A1 200 ppi – 3.5 sec. 400 ppi – 5.9 sec. 600 ppi – 7.6 sec. |
Scanner interface | Camera Link |
Zoom | A1 – A2 |
Resolution | 100 – 600 ppi |
Electrical data/safety | |
Voltage | 110 – 240 V |
Frequency | 50 – 60 Hz |
Max. Consumption |
440 W |
Safety inspections / authorizations |
– Authorization in accordance with the IEC agreement (international authorization for the safety of IT products – includes EMC, electrical safety, device safety for CE, UL, ETL, CSA) – LEDs tested in accordance with: IEC 62471:2006 “Photobiological safety of lamps and lamp systems” |
Dimensions | |
Width | 1370 mm / 53.93″ |
Depth | scanner including copy board system – 2200 mm / 78.74″ |
Height | 2144 mm / 84.40″ |
Copy board system | OT 180 H50 XL, OT 180 H35 XL, OT 180 H, OT 180, AT 1, OT 90, vacuum table |
Accessories for copy board systems |
Kit 90°, book holder 110° – 140° |
Recommended working conditions | |
Temperature range | 18 – 35 °C |
Relative air humidity, non-condensing |
80 % |
Operating System | Windows 10 64 bit |
Capturing Software | min. OmniScan OS 12.12 64 bit |
Technical changes reserved
Zeutschel ScanStudio kombinerer en verden av profesjonelle skannere med en verden av studiofotografering.
Sentrale utstyrsfunksjoner er et kamerasystem med digital bakside opp til 150 MP, høyytelses utskiftbare linser, spesiell ErgoLED-belysning med fleksibel lysføring, samt et bredt utvalg presentasjonsbord og opptakssystemer.
Bildekvaliteten overgår spesifikasjonene til de etablerte digitaliseringsstandardene og retningslinjene ISO 19264-1, Metamorfoze og FADGI. Skarpe bilder med lite støy og høy kontrast oppnås. Selv de fineste detaljene er trofast gjengitt.
De tilgjengelige opptaksbordene, bokvuggene og en transparentenhet med holdere for de vanligste filmformatene sikrer høy produktivitet under digitalisering og ergonomisk betjening.
Hovedfunksjoner og produktfordeler:
OS 15000 Comfort: Den multifunksjonelle enheten for dine digitaliseringsoppgaver.
Den imponerer med sin ekstraordinære design, leverer utmerkede data og er veldig enkel å betjene takket være den velprøvde Omniscan 12-programvaren.
Med et maksimalt overflateareal på 460 x 360 mm og en oppløsning på 600 dpi ved 42-bits fargedybde, kan selv store bøker og dokumenter digitaliseres uten problemer. Takket være den nye systemdesignen blir ikke brukeren blendet under arbeid og originalen er beskyttet på best mulig måte. Alle standard bildeformater er mulige for datautgang.
De viktigste funksjonene og produktfordelene:
Zeutschel OS A Overhead Scanner: Bildefangst med utvalgte digitale kameraer av semi-profesjonell og profesjonell klasse.
Digitaliserer heterogene samlinger i en gjennomgående høy bildekvalitet med maksimal produktivitet og fleksibilitet.
Zeutschel OS A: Overheadskanner for høye krav til perfeksjon og gjennomførbarhet
Zeutschel OS A er en modulært utformet, universelt anvendelig overheadskanner for et bredt utvalg av originaler – fra filer, bøker og dokumenter til bilder, lysbilder og malerier til mynter og segl.
Viktige funksjoner og fordeler inkluderer:
CZUR ET25 Pro
Bokskanner som skanner bøker og dokumenter i A3-format. 25 MP HD-kamera. Skanner 1 side på 1 sekund. Retter ut kurver i oppslått bok. Farger, gråtoner, sort/ hvitt. Fremhev mønstre, stempelavtrykk og annen dårlig trykk. Intelligent prosessprogramvare. Antirefleks. Oversiktlig presentasjon av skannede filer.
God og rimelig bokscanner, bedre kamera, raskere skanning
kr 6 990,00
Legg i handlekurvToppmodellen fra CZUR.
Bokscanner som scanner bøker, dokumenter, bilder, mm. opp til A3-format. 28 MP HD-kamera. Scanhastighet ca. 1,2 sekunder. V-formet bokkrybbe. Retter ut kurver i oppslått bok. Farger, gråtoner, sort/ hvitt. Fremhev mønstre, stempelavtrykk og annen dårlig trykk. Intelligent prosessprogramvare. Antirefleks. Oversiktlig presentasjon av skannede filer. Oppløsning: 6144x 4608 pixler.
360 DPI. 24 Bit farger. 32 Bit prosessor.
Se alle spesifikasjoner nedenfor.
PROGRAMVARE:
Windows 7/8/10: Last ned programvare for CZUR M3000 Pro ved å trykke HER
Mac: Last ned programvare for CZUR M3000 Pro ved å trykke HER
kr 24 990,00
Legg i handlekurvHøykvalitetsscanner med brukervennlig tablet pc, for scanning av bøker, etc. Med bokkrybbe for balansering av bøker, etc. Scanner opp til 300 ppi. Opsjon: 600 ppi. Scan format: 48×36 cm, som ligger mellom A2 og A3. Beregnet for publikumsbruk med lagring til minnepinne, og for direkte utskrift. Tablet touchscreen for enkel publikumsbruk.
